Description
• Equipped with ball bearings for smoother rotation and higher load capacity, delivering excellent performance and reliability.
• The sheaves are manufactured from stainless steel, making them compatible for use with steel cables.
Specifications:
• Compatibility: Rope ≤ 13 mm; Steel Cable ≤ 12 mm
• Dimensions: 87 × 107 × 31 mm
• Sheave Diameter: 28 mm
• Minimum Breaking Strength (MBS): ≥ 22 kN
• Materials: Side Plates - Aluminum Alloy; Sheaves - Stainless Steel; Bearings & Axle - Steel
• Certification: XF494-2004, GB/T 6461-2002
• Weight: 268 (±1) g
